CNC Kit Ballscrew SFU RM2505 + Linear Slide Guide Rail HGH25 2000mm, with Ball Screw Nut + BK/BF20 End Supports + Coupler + Nut Housing + Motor Bracket for Nema 34 + Bearing Slider Block

Specifications: Brand: BopaodaoBallscrew Manufacturing Process and Precision: Rolled Thread, with C7 Grade (C5 is also available, please contact us)This package includes:- 1Pcs Ball Screw SFU2505 RM2505 20mm Length 78.74 inch / 2000mm (You can message us to know the travel/stroke length and thread length) - 1Pcs Metal Deflector Ball Screw Nut- 1Pcs BK20/BF20 End Support Bearing Blocks and Motor Bracket for Nema 34 stepper motor with locknuts, circlips and mounting screws (BK support end and Motor Bracket are integrated, and the bearing in the BK is deep groove ball bearings, if you need angular contact bearings, pls tell us)If your motor is Nema 32 servo motor, we could also provide the motor bracket to match, please let us know - 1Pcs Coupler / Coupling (Standard for motor shaft 14mm, if not, tell us and we will manufacture it free for you)- 1Pcs Ball Screw Nut Housing- 2Pcs HGH25 Square Linear Rails Guideway, Length 78.74 inch / 2000mm- 4Pcs HGH25CA Bearing Carriage Sliding Block ( High Assembly and Square Slider )Besides the HGH CA block, there are EGH CA block ( Low Assembly and Square Slider ), and HGH HA block ( Long, High Assembly and Square Slider ). If you have needs, please give us Amazon MessageLead Time: If this item is not FBA, the lead time is 7-10 Business Days except for for Chinese National Day holiday and Spring FestivalCustomizable Processing and Technical Support:1. We can provide any length that you want, and please let us know what lengths are suitable for you.2. If you need end machining according to your drawings, please tell us before order.3. As a professional seller, we can provide complete information of the products.（Contains CAD drawings and 3D modeling files）Please contact us.

• Ball screw diameter: 25mm; Lead / Pitch: 5mm; Total length: 78.74 inch / 2000mm; Nut + BK20 integrate with Motor Bracket for stepper motor Nema 34/BF20 End support with locknuts and circlips + Flexible coupler + Ball Screw Nut Housing. The diameter of the coupler which matches the motor shaft is 14mm in default, if your size is other, pls tell us
• The ball screw kit can ensure motor shaft, coupling axial, axial bearing hole, and screw axis all in a line strictly, to make the transmission system run more accurately and sturdily, less noise and longer life. The material of the bk bearing support and Motor Bracket is cast steel, high hardness, shock resistance and high precision machining
• The ballscrew is no stick-slip effect, heats up less, reduce driving power required, small starting torque, able to apply high speed and micro-feeding
• 2Pcs linear rails HGH25 25mm length: 78.74 inch / 2000mm, 4Pcs HGH25-CA bearing slider carriage blocks. Strong bending resistance, difficultly deformed and twisted, ensuring precise linear motion, have high accuracy of the trajectory
• Innovative slider technology, smooth, low friction, high speed and silent operation. Can withstand the load in all directions with four-direction equal load characteristics and self-aligning to absorb installation-error
